1–12 Maintenance and Service Guide
Product Description
The computer top components are shown in Figure 1-5 and
described in Table 1-9.
Figure 1-5. Top Components
Table 1-9
Top Components
Item Component Function
1 Display lid switch Turns off the computer display if the
computer is closed while on.
2 Power light On: Power is turned on.
Blinking: Computer is in Suspend mode.
The power light also blinks if a battery pack
that is the only available power source
reaches a low-battery condition.
3 Num lock light On: Num lock is on and the embedded
numeric keypad is enabled.
4 Easy Access
Buttons (3)
Provide quick access to the Internet. Refer
to the
Hardware Guide
that ships with the
computer for information about these
buttons.
268135-002.book Page 12 Thursday, October 24, 2002 4:10 PM
