Operating the Monitor 2-3
Part Number 264154-001 - - Writer: Marianne Silvetti - Saved by Troy Witte - Saved date: 08/29/97
2:11 PM
File Name T:\docs\codename\partnumber\CH2.DOC
Display Resolutions
The display resolutions listed below are the most commonly used
modes and are set as factory defaults. The monitor automatically
recognizes these modes when they are requested by a software
program.
Display Resolutions
Memory Channels Resolutions
1 1024 × 768 at 60.0 kHz/75 Hz
2 1024 × 768 at 48.4 kHz/60 Hz
3 800 × 600 at 53.7 kHz/85 Hz
4 800 × 600 at 46.9 kHz/75 Hz
5 800 × 600 at 37.8 kHz/60 Hz
6 720 × 400 at 31.5 kHz/70 Hz
7 640 × 480 at 43.3 kHz/85 Hz
8 640 × 480 at 37.5 kHz/75 Hz
9 640 × 480 at 31.5 kHz/60 Hz
10 640 × 350 at 31.5 kHz/70 Hz
User Modes
Occasionally, the video controller signal may call for a mode that is
not preset. This may occur for one of the following reasons:
■ You are not using a Compaq standard graphics adapter.
■ You are not using a preset mode.
If this occurs, you may need to readjust the size and centering of the
monitor screen by using the on-screen display. The monitor
automatically stores the new setting as a user mode, then
automatically recognizes the new user mode just as it does a preset
mode. Up to eight user mode settings can be stored.
