257
English
The On/Off button is a multi-
function button (symbol no. 5009
IEC 60878).
Functions
On/Off (two stable positions)
Waiting or preparation for part of the unit
Stop (turns system off)
10. Technical
characteristics
General information
941210 Battery unit
N
ickel metal hybrid (NiMH) rechargeable
(4.8V / ≥ 1,200 mA/h).
68301x Chargers
O
nly battery chargers bearing the
following information can be used to
recharge the batteries supplied with
Compex stimulators:
Europe
683010
Type TR1509-06-E-133A03
Input 90-264 VAC / 47-63 Hz / 0.5 A max.
Output 9 V / 1.4 A / 15 W
UK
683012
Type TR1509-06-U-133A03
Input 90-264 VAC / 47-63 Hz / 0.5 A max.
Output 9 V / 1.4 A / 15 W
601131 Black Snap-connection
stimulation cables
Device connector: 6-pin
Electrode connector: Female Snap
Length: 1,500 mm
601160 Stimulation cable fitted
with
m-4
(accessory sold separately)
Device connector: 6-pin
Electrode connector: Female Snap
Length: 1,500 mm
Protection index
IPXO (IEC 60529)
Neuro-stimulation
All electrical specifications are given for
an impedance of 500-1,000 ohms per
channel.
Channels: Four independent and individually
adjustable channels that are electrically isolated
from each other and earthed.
Pulse shape: constant rectangular current with
pulse compensation to eliminate any direct
current component to prevent residual
polarisation at skin level.
Maximum pulse intensity: 120 mA.
Pulse intensity increments: manual adjustment of
stimulation intensity from 0 to 999 (energy) in
minimum increments of 0.5 mA.
Pulse width: 60 to 400 µs.
Maximum electrical charge per pulse:
96 microcoulombs (2 x 48 µC, compensated).
Standard pulse ramp-up time: 3 µs (20%-80% of
maximum current).
Pulse frequency: 1 to 150 Hz.
PERFORMANCE FR DE IT ES EN:ENGY Man FR 14/02/08 15:11 Page 257
