English 24-port 10/100Mbps Fast Ethernet Switch
with Power Buttons
SAS2224
9
LEDs Description
Two function groups, namely Display LED group and Configuration LED
group, can be selected from the Mode button:
Display LED: To select general port operation status
Function Description
Link/Act Display all active ports link and activity status.
10/100M Display all active ports speed. ON for 100Mbps, OFF for
10Mbps.
Display all active ports Duplex mode and collision status.
ON For Full-Duplex mode
OFF For Half-Duplex mode.
Full/Col
Blinks Indicate collision is active. This occurs only when
port is operating in Half-Duplex mode.
Configuration LED: To configure the ports and set Priority/VLAN operation
Function Description
Priority Set priority of the ports
VLAN1/3 Set/reset/view pre-set VLAN1/3
VLAN2/4 Set/reset/view pre-set VLAN2/4
100M Set/reset/view pre-set speed for all ports.
Half Set/reset/view pre-set duplex mode for all ports.
To Next Page
