Compex SAS2224 User Manual

4 24-port 10/100Mbps Fast Ethernet Switch
with Power Buttons
SAS2224
English
5. Panel Features
Features Status and Indication
1 MODULE LED ON indicates an optional module had been installed.
2 POWER LED ON indicates power is supplied to Compex SAS2224.
3 Set Button To configure port mode.
4 Mode Button To view port status and select option mode.
5 24 LEDs To indicate the status of port configuration on individual port.
6 Display LED To view active ports Link/Act, 10/100M, Full/Col status.
7 Configuration LED To configure port Priority, Speed, VLAN, Full/Half mode.
8 24 RJ-45 Ports RJ-45, 100Base-TX/10Base-T ports; Auto-negotiation.
9 Reset Button To reboot Compex SAS2224.
10 Module Slot For optional 100Base-FX Fiber Module and AUI Module
11 Power Socket Flexible power input (range 100VAC to 240VAC)

Compex SAS2224 Specifications

General

Brand	Compex
Model	SAS2224
Category	Switch
Language	English
