English 24-port 10/100Mbps Fast Ethernet Switch
with Power Buttons
SAS2224
13
VLAN 2
1. Press the Mode button several times until the VLAN2 LED lights up. You will notice
that ONLY individual LED will flash in sequence for a few seconds, starting from
Port #1 to Port #24.
2. Press Set button once when the desired port is flashing. ONLY the selected port LED
will light up for VLAN 2. This shows that the port has been selected for VLAN 2.
3. To save your configuration, press Set button and hold it down for about 3 seconds
until the selected LEDs keep flashing.
4. To set up ports in VLAN 3, please press the Mode button to VLAN 1/3 LED and
repeat the procedures for setting VLAN 2.
To set up port in VLAN 4, please repeat the procedures in VLAN2.
9.6. How to force a certain port to 100Mbps speed and Half or Full-duplex mode
1. Press the Mode button several times until the 100M LED lights up. Check the LED
for that port number you want to set.
2. If the port that you want to set as 100M has already lighted up, you may proceed to
Step 7 – Setting Port as Full/Half duplex, or else please proceed to next step.
3. The port LEDs will flash in sequence from port #1 to Port #24. Press the Set button to
confirm the desired port to configure in 100M.
4. When selected, the port will remain lighted up for 100M mode. For 10M, the LED
will turn off.
5. To save your configuration, press the Set button and hold it down for about 3 seconds
until the all LEDs flashing thrice.
6. Next press the Mode button until the Half LEDs lights up. Check the LED for the port
number you want to set.
