Compex SAS2224 - 4 Panel Views

English 24-port 10/100Mbps Fast Ethernet Switch
with Power Buttons
SAS2224
3
10 11
6 7
1 2 3 4 5
8 9
4. Panel Views
Figure 4.1 Front Panel View of Compex SAS2224
Figure 4.2 Front Panel View of Compex SAS2224 (Section #1)
Figure 4.3 Front Panel View of Compex SAS2224 (Section #2)
Figure 4.4 Back Panel View of Compex SAS2224
