English 24-port 10/100Mbps Fast Ethernet Switch
with Power Buttons
SAS2224
15
If it is not lighted up, it indicates that the port is already in 10Mbps mode and the
setup has completed. Or else please proceed to the next step.
7. The port LEDs will flash in sequence from port #1 to port #24. Press the Set button
once when the desired port is flashing.
This port LED will remain lighted for 100M mode if selected. For 10M mode, the
LED will turn OFF.
8. After selecting the desired ports, press the Set button and hold it down for about 3
seconds until all LEDs flashing. When succeeded, the port LED you have set will
remain lighted up. Setup complete.
NOTE
10Mbps and Full-Duplex combination is not supported.
100M LED Half LED Port Status
ON ON Forced to 100Mbps speed and Half-Duplex mode
OFF ON Forced to 10Mbps speed and Half-Duplex mode
ON OFF Forced to 100Mbps speed and Full-Duplex mode
OFF OFF Reset to normal auto-negotiation mode
To Next Page
