English Compex 24-Port + 1 Expansion Slot Switch
SAS2224B
3
2. Hardware Installation
Compex SAS2224B can be installed as a desktop unit or mounted on a 19-inch rack. Detailed
installation process will be listed as shown.
2.1. Desktop installation
Insert one end of RJ45 network cable to any
port of Compex SAS2224B and the other
end to your PC.
Insert the power cord to the socket
located at the back of Compex
SAS2224B and the other end to the
power point.
Check that the Power LED at the front
panel of Compex SAS2224B has lighted
up. The unit is now ready to use.
Insert one end of RS232 straight console
cable to the console port of Compex
SAS2224B and the other end to your PC.
