17
COMPRAG RDX series compressed air refrigerated dryer
К5 Timer M1 Compressor
S1. Start/Stop Button M2 Fan
F1 Fuse A1 Condensate drain valve
V1 Plug S1 Fan pressure switch
F Temperature switch
3.5 Electrical connection
Fig.3.5.1 V.2 Electric schematic diagram RDX 04-77
