COMPRAG RDX series compressed air refrigerated dryer
2. Technical data and functional description
Entitlement to free handling of faults arising during the guarantee pe-
riod is forfeited when:
- No warranty service coupon for the compressor or it is lled out
incorrectly
- No records for the compressor’s scheduled maintenance are entered
in the compressor’s service book
- Unoriginal parts and lubricants are used
2.1 Technical data
Model RDX04 RDX06 RDX09 RDX12 RDX18
Article 14310000 14310001 14310002 14310003 14310004
Capacity*, (m
3
/min) 0,4 0,6 0,9 1,2 1,8
Maximum working pressure, bar 16
Maximum inlet temperature of
compressed air,
0
C
+55
Maximum ambient temperature,
о
С +45
Pressure dew point,
0
C +3
Type of refrigerant R134a
Quantity of refrigerant, kg 0,16 0,21 0,24 0,30 0,35
Thread connection, internal thread G1/2“ G3/4“
Power supply 1/230 V – 50 Hz
Power required, kW 0,10 0,13 0,15 0,22 0,23
Model RDX24 RDX30 RDX36 RDX41
Article 14310005 14310006 14310007 14310008
Capacity*, (m
3
/min) 2,4 3,0 3,6 4,1
Maximum working pressure, bar 14
Maximum inlet temperature of
compressed air,
0
C
+55
Maximum ambient temperature,
о
С +45
Pressure dew point,
0
C +3
Type of refrigerant R404a
Quantity of refrigerant, kg 0,40 0,40 0,51 0,51
Thread connection G1“, internal thread
Power supply 1/230 V – 50 Hz
Power required, kW 0,44 0,56 0,65 0,77
