Comprag RDX12 - Turning on Dryer; Turning off Dryer

22
Version 2.2
Pressure value: R 404 A Shutdown at 30 bar (64,2°C) - Manual start-up at 24 bar (54,0°C).
4.2 Before use and on a weekly basis
Ensure the dryer’s power cable is intact.
Ensure that the compressed air hoses are connected to the compressed air inlet and outlet
of the dryer.
4.3 Turning on dryer
Do not permit unqualied personnel to use the dryer
1. Turn the main switch from position “0” to position “1”.
2. The indicator ‘Dryer ON’ lights up.
3. Press the Start button.
4.4 Turning off dryer
Do not turn off the dryer if the compressed air system is under
pressure.
The dryer is turned off by pressing the Dryer OFF button on the control panel and turning
the main switch from position “1” to position “0”.
