7-3
CAT-200B Programming Information
Nine new voice variables have been added to the vocabulary list to announce weather information during
the repeater ID or other voice messages.
VARIABLE DESCRIPTION EXAMPLE (VARIABLE IN BOLD)
110 INSIDE TEMPERATURE 75 Degrees
111 OUTSIDE TEMPERATURE 40 Degrees
112 WIND SPEED AND DIRECTION The wind is out of the EAST at 10 miles per hour
113 RAIN FALL Today’s rain fall is .2 inches
114 ONE MINUTE WIND SPEED The one minute wind speed is 25 miles per hour
115 HIGH / LOW TEMPERATURE
116 WIND CHILL
117 AIR PRESSURE
118 HUMIDITY
Program Voice Message With Temperature Variables
To program a voice message with the temperature load the number [111]. Example: Load message 3
with the actual temperature. The voice will say: "THE TEMPERATURE IS 75 DEGREES]"
Message Number Actual Temperature
*31 03 830 824 482 111
