7
0416
Wall mounted: Hardware is included for attaching the SkiErg to a wall with 16” wooden stud spacing. For mounting to other types
of wall construction (metal, concrete, etc.), please consult with a building professional for safe and secure installation. See below for
installation recommendations. Dimensions (without user): 20.5 in x 16 in x 83.5 in (52 cm x 40.6 cm x 212 cm). Training area: 24 in x
52 in x 85 in (61 cm x 132 cm x 215.9 cm). Weight: 46 lb (21 kg).
Free standing: The optional floor stand with built-in caster wheels allows for use on any level surface. Some assembly is required.
Dimensions: 24 in x 52 in x 85 in (61 cm x 132 cm x 215.9 cm). Floor Stand Weight: 35 lb (18 kg).
HINT: Read through the instructions before beginning. It will be helpful to have another person assist with the installation.
Wall Mounting Instructions for a Wall with 16” Wooden Stud Spacing - page 12
The SkiErg must be securely and reliably fastened to a solid wall. The SkiErg comes with pre-drilled holes for a standard 16” on
center stud wall construction.
SAFETY NOTE: If you are unsure that your walls have wooden studs at 16” spacing, you should not continue installation until you
determine the spacing of the studs. If the studs are spaced at a dimension other than 16,” you must follow the alternate installation
instructions on page 15. If you are still unsure about the spacing of the studs do not continue installation until you have made the
correct determination.
EN
INSTALLATION INSTRUCTIONS
FR
Montage mural : Le matériel est inclus pour fixer le SkiErg à un mur à montants en bois espacés de 40 cm. Voyez les
recommandations d’installation ci-dessous. Note importante : La construction du mur varie selon les pays. Pour le montage sur
d’autres types de cloison (métal, béton, etc.), veillez à consulter un professionnel du bâtiment pour vous assurer que l’installation est
sûre et sécurisée. Dimensions (sans utilisateur): 52 cm x 40,6 cm x 212 cm. Zone d’entraînement : 61 cm x 132 cm x 215,9 cm. Poids :
21 kg.
Autonome : La plateforme optionnelle à roulettes intégrées permet une utilisation sur n’importe quelle surface plane. Elle est livrée
non montée et requiert un assemblage. Dimensions : 61 cm x 132 cm x 215,9 cm. Poids de la plateforme : 18 kg.
NOTE : Lisez toutes les instructions avant de commencer L’aide d’une autre personne sera utile pendant l’installation.
Instructions de montage mural pour un mur à montants en bois espacés de 40 cm
Le SkiErg doit être sécurisé et fixé de manière fiable à un mur plein. Le SkiErg est livré avec des avant-trous percés pour un mur de
construction standard de 40 cm entre centres des montants (standard USA).
CONSIGNE DE SÉCURITÉ : Si vous n’êtes pas sûr que vos murs aient des montants en bois espacés de 40 cm, vous ne devriez pas
continuer l’installation avant d’avoir déterminé leur espacement. Si les montants sont espacés à une dimension autre que 40 cm,
suivez les instructions d’installation alternative à la page 15. Si vous n’êtes toujours pas sûr de l’espacement des montants, arrêtez
l’installation jusqu’à ce que vous l’ayez déterminé correctement.
NOTICE DE MONTAGE
DE
Wandmontage: Im Lieferumfang befinden sich Beschläge, mit denen Sie Ihren SkiErg an einer Wand befestigen können. Die
passenden Dübel für Ihre Wand-Art werden jedoch nicht mitgeliefert. Sollten Sie Hilfe bei der Befestigung von Ihrem SkiErg
benötigen, wenden Sie sich bitte an einen Fachmann. Eine Montageanleitung finden Sie auf den nächsten Seiten. Maße: (ohne
Benutzer) 52cm x 40,6cm x 212cm, (bei Benutzung) 61cm x 132cm x 215,9cm, Gewicht 21kg.
Freistehend: Der SkiErg Floorstand mit seinen eingebauten Transportrollen bietet Mobilität und Flexibilität. Der SkiErg Floorstand
lässt sich in wenigen Handgriffen zusammenbauen. Maße: 61cm x 132cm x 215,9 cm. Gewicht des SkiErg Floorstands: 18kg.
Tipp: Lesen Sie bitte die Anleitung bevor Sie mit der Montage beginnen. Der Floorstand lässt sich am einfachsten zu zweit
zusammenbauen.
Wandmontage
Der SkiErg soll nur an eine stabile Wand montiert werden. Die oberen und unteren Haltewinkel sind zur Wandmontage mit jeweils 2
Bohrungen versehen.
Wichtig: Wenn Sie sich bei der Wandmontage des SkiErgs unsicher sind, kontaktieren Sie bitte einen Fachmann und lassen diesen
die Montage durchführen.
MONTAGEANLEITUNG
