Figure 3.
5.3 Accessories
A. a hanging rope
B. two dry batteries(AAA) (optional)
C. a user manual
D. a data line
E. a disk (PC software)
6 Operating Guide
6.1 Application method
A.
a) Insert the two batteries properly to the direction, and then replace the cover.
b) Open the clip as shown in Figure 4.
c) Let the patient’s finger put into the rubber cushions of the clip (make sure the finger is in the right
position), and then clip the finger.
d) Do not shake the finger and keep the patient in a stable state during the process.
e) The data can be read directly from the screen on the measuring interface.
Fingernails and the luminescent tube should be on the same side.
If the alarm function is on, the device will provide medium-priority alarm signal when
finger is out. Intermittent alarm will occur and the user interface presents "FINGER OUT".
Medium priority indicating that prompt operator response is required.
Figure 4. Put finger in position
CMS-50D Plus
