2. Hardware Installations

SPI-8150-LVA, SPI-8151-LVA

2.15 CD Audio connector: CN16

This connector is used to connect CD Audio cable from CD-ROM or DVD drive to

onboard sound.

PIN No. Function

1 L

2 GND

3 GND

CN16

1 2 3 4

4 R

2.16 AC97 Sound connector: CN17

PIN No. Function PIN No. Function

1 LINE-OUT-R 2 LINE-OUT-L

3 GND 4 N.C.

5 MICPWR 6 MICIN

7 GND 8 GND

CN17

1 2

9 10

9 LINE-IN-R 10 LINE-IN-L
