1. Introduction
2
SPI-8150-LVA, SPI-8151-LVA
y Watchdog Timer: Software programmable 15 levels, Reset or NMI (Jumper
selectable)
y IrDA: One 1x6 Pin-header
y Keyboard / Mouse connector: One PS/2 keyboard/Mouse MiniDIN
6-pinsconnector and one 5-pins box-header for external keyboard
y VGA/LCD Connector: DVI interface *2
y Audio: Support AC97 Codec integrated in ICH2.
y LAN1: Intel ICH2 integrated with Intel 82562ET chipset
Wake On LAN support
y LAN2: Intel 82551 LAN controller
Wake On LAN support
y SSD Socket : DIP socket supports DiskOnChip flash disks (2MB - 144MB)
y CF Slot : Slot supports Compact Flash card (Power +5V, PCMCIA-ATA standard,
TypeI/II type card correspondence). Connecting to the Secondary IDE.
y RTC: battery backup by Lithium Battery (CR2450)
The clock is accurate to ±3 minutes/month at 25°C.
The coin type Lithium battery specification is shown in table
Model CR2450
Nominal Voltage 3V
Nominal Capacity 620mAh
Nominal Weight 6.3g
* The maximum using duration of CR2450 Battery is over 8 years at 20
o
C.
y Operating System Support:
Windows XP Professional/ Home Edition
Windows 2000 Professional
Windows 98SE
Windows NT Workstation 4.0
*3
*1 The number of drives includes a CF card inside the CF slot.
*2 The interface can connect to a CONTEC Panel Link input type display (using an
optional cable) or an ordinary analog RGB input display (using the bundled DVI-analog
RGB adapter).
*3 USB is not supported.
