Conti MONTE-CARLO - 16 Electric Designations

MONTE-CARLO - 11/2015 - SOFT V 2.11 45
16 ELECTRIC DESIGNATIONS
REFERENCES
DESIGNATIONS
BAF
Fuse box
CN i
Connector n° i
CP i
Coffee buttons GROUPE n° i
CV i
Flow meter GROUPE n° i
D
Circuit breaker 25 A
EC
Tea solenoid valve.
EE
Inlet valve
EV i
Coffee solenoid valve n°i
F1
Fuse 3.15A
F2
Fuse 1A
K TE
Tea key 1
K VAP
Steam key
LCDi
Connector DISPLAY GROUPE i
LV
Steam Control system probe
MP
Pump
ON / OFF
On / Off button
SV
Temperature sensor for steam boiler
RCCi
Heating element group n° i
RCi
Heating element n° i for steam boiler
RS
Security relay.
RV i
Adjustment of the display contrast groups n° i
SN
Level probe
SS
Security probe
ST i
Temperature sensor group n° i
STR
Auxiliary contact of relay RS
TSi
Coffee boiler n° i security thermostat
TSV
Steam boiler security thermostat
VAP
Steam solenoid valve for steam control (option)
Pi
Bleeding solenoid valves Gr i
CODE COULEURS FILS
CABLE COLOUR CODE
1
marron
brown
2
rouge
red
3
orange
orange
4
jaune
yellow
5
vert
green
6
bleu
blue
7
violet
violet
8
gris
grey
9
blanc
white
0
noir
black
