16
zones and any assigned input sources (such as Input 1 as
shown in the following screen).
A shaded arrowhead indicates that a signal is present.
The menu buttons on the front panel provide access to the
following screen:
Setup: Displays an output-specific screen, such as
Output Zone 1.
Network: Displays the Network Configuration screen.
Display: Displays the Display Configuration Screen.
NOTE: After leaving the Setup, Network, or Display
menu and returning to the In to Out Assignments screen,
you may need to wait for the screen to load before
selecting another menu.
