CHAPTER
1 Introduction to Multi
Channel Amplifier - 16
Control4 systems are uniquely configured for every
customer and every site. A popular component among
music lovers is the Control4 Multi Channel Amplifier.
This chapter introduces the Control4 Multi Channel
Amplifier - 16 and its features.
Features and Benefits
 Receives up to eight stereo inputs with full audio
switching on inputs.
 Outputs eight stereo class D amplified channels at
120 W per channel at 8 ohms or at 220 W per channel
at 4 ohms (not all channels driven simultaneously).
 Adjustable gain, treble, and bass for each zone
 Master Volume Control for all outputs
 Control4 EZ ID
™
LEDs for every I/O to make
connections easy to identify
 Device chassis is three standard rack spaces and
rack mountable using 4 standard rack spaces
configuring to EIA 19” rack standards. The optional
Control4 Rack Mount Kit (C4-4URMK-B) provides 1/2
U spacing above and below the chassis. If the
Control4 Rack Mount Kit is not used, allow ½ rack
space above and below the chassis for ventilation.
 Communicates via Ethernet 10/100 port and ZigBee
mesh networking (IEEE 802.15.4).
