RJ-45 M odular Jack
Grey
1.
+Tx
2.
–Tx
3.
+Rx
4.
5.
6.
–Rx
7.
8.
21 876543
10BaseT has a maximum run of 100m or 350 feet, but the actual limit is based on signal loss and the
noise in the environment. This may limit the practical distance to less than 100m or 350 feet. The
Ethernet cables should not be run in parallel with power or any cables that generate noise.
SCADAPack 32P Controller Hardware Manual
May 26, 2006
28
