Control Microsystems SCADAPack 32P User Manual

8 Specifications
Disclaimer: Control Microsystems reserves the right to change product specifications without
notice. For more information visit
www.controlmicrosystems.com .
8.1 General
I/O Terminations
6,8,9 and 10 pole, removable terminal blocks.
12 to 22 AWG
15A contacts
Dimensions
8.40 inch (213mm) wide
6.13 inch (155mm) high
1.75 inch (44mm) deep
Packaging
corrosion resistant zinc plated steel with black enamel paint
Environment
5% RH to 95% RH, non-condensing
–40
o
C to 70
o
C
–40
o
F to 158
o
F
8.2 SCADAPack 32P Controller
Processor
Hitachi SH-3 32-bit CMOS microcontroller
120 MHz. clock
Memory
4Mbytes Flash
8Mbytes SDRAM
1024kBytes CMOS RAM
Non-volatile
RAM
CMOS RAM with lithium battery retains contents for 2 years
with no power
Clock calendar
±1 minute/month at 25°C
+1/–3 minutes/month 0 to 50°C
Internal
temperature
Measurement range -40°C to 75°C. Accuracy ±5°C.
Measurement range -40°F to 167°F. Accuracy ±9°F.
Lithium battery
monitor
Accuracy ±0.2V.
8.3 Communications
Communication
Ports
2 RS-232 serial ports (COM2, COM4)
Data Terminal Equipment (DTE)
8 pin modular jack
Communication
Ports
One serial port configurable RS-232 or RS-485 (COM1)
RS-232:
Data Terminal Equipment (DTE)
8 pin modular jack
RS-485:
2 wire half duplex
4 wire full or half duplex
optional termination resistors
Baud Rates
(COM1, COM2,
COM4)
300, 600, 1200, 2400, 4800, 9600, 19200, 38400, 57600 and
115200.
SCADAPack 32P Controller Hardware Manual
May 26, 2006
37

Control Microsystems SCADAPack 32P Specifications

General

Brand	Control Microsystems
Model	SCADAPack 32P
Category	Controller
Language	English
