24 Commander SK Size 2 to 6 Getting Started Guide
www.controltechniques.com Issue Number: 2
Figure 3-16 Through-panel mounting of a size 6 drive
In order to achieve IP54 rating and/or NEMA 12 for through-panel
mounting, an IP54 insert must be fitted (size 2) and the heatsink fan
must be replaced with an IP54 rated fan (size 2 to 4). Additionally, the
gasket provided should be fitted between the drive and the backplate to
ensure a good seal for the cubicle. See section 3.4 IP Rating (Ingress
Protection) on page 25
310mm (12.205in) 200mm (7.874in)
1105.6mm
(43.528in)
∅
8.5mm
(0.335in)
∅
8.5mm
(0.335in)
1131mm
(44.528in)
1179.3mm
(46.429in)
98mm
(3.858in)
298mm (11.732in)
258.6 0.5mm
(10.181 0.020in)
±
±
286.0 0.5mm
(11.260 0.020in)
±
±
1107.8 0.5mm
(43.614 0.020in)
±
±
27.1 0.5mm
(1.067 0.020in)
±
±
13.7±
±
0.5mm
(0.539 0.020in)
258.6 0.5mm
(10.181 0.020in)
±
±
1161.2
0.5mm
(45.717
0.020in)
±
±
R6.5mm
(0.256in)
R6.5mm
(0.256in)
NOTE
