UD53 User Guide
Issue code: 53nu3
Drive software V03.xx.05 or earlier
UD51 version 3 or earlier
(either or both present)
The Z marker-pulse outputs are sychronized to the simulated-encoder
quadrature AB outputs only when the resolution of the AB outputs is
equal to or greater than 1
LPR.
Drive software V03.xx.04 or earlier
No simulated-encoder outputs are available.
