194 Unidrive User Guide
www.controltechniques.com Issue Number: 9
* Cable lengths in excess of the specified values may be used only
when special techniques are adopted; refer to the supplier of the
drive.
** The default switching frequency for all versions of Unidrive is 3kHz,
except Unidrive LFT, which is 9kHz.
See section 4.5.1 Cable types and lengths on page 41 for further
limitations on motor cable length.
11.1.16 Unidrive size 5 output sharing choke
specification
Minimum inductance: 40µH
Frequency range: 0Hz to maximum motor frequency
Current rating: 300A RMS
Overload current: 120% rated current for 1 minute in a 10 minute period
Harmonic current: 10% at 3kHz
Saturation level: 200% rated current
Ambient temperature: 55°C (130°F) max.
Temperature rise: 100°C (212°F) max.
Cooling: Convection
Insulation class H (180 °C) or better
High-potential test – winding to core: 2.5kV at 50/60 Hz
High-potential test – between windings: 2.5kV at 50/60 Hz
11.1.17 Braking resistor values
11.1.18 Acoustic noise
The fan generates the majority of the acoustic noise produced by the
drive. The Unidrive LFT has a slower speed fan than the Unidrive or
Unidrive VTC and hence generates less noise. Unidrive LFT sizes 1 and
2 are fitted with temperature controlled variable speed fans that run at
the minimum speed until the temperature reaches 30
o
C (86
o
F) and
increase in speed until the temperature reaches 45
o
C (113
o
F), where
they will be running at the maximum speed.
Values quoted are at a distance of 1m from the drive.
11.1.19 Torque settings (Drive and filters)
Table 11-4 Drive power terminal data
Table 11-5 Drive control terminal data
Table 11-6 Size 5 fan supply connection
Nominal
AC supply
voltage
400V 480V
Model
Maximum Permissible Motor Cable Length *
(PWM switching frequency at 3kHz **)
mftmft
UNI1401 65 210 50 160
UNI1402 100 330 75 250
UNI1403 130 430 100 330
UNI1404 200 660 150 490
UNI1405 300 990 250 820
UNI2401 to
UNI2403
300 990 300 990
UNI3401 to
UNI3405
200 660 124 410
UNI4401 to
UNI4405
200 660 124 410
UNI5401 300 990 300 990
UNI5402 600 1,980 600 1,980
UNI5403 900 2,970 900 2,970
UNI5404 1,200 3,960 1,200 3,960
UNI5405 1,500 4,950 1,500 4,950
UNI5406 1,800 5,940 1,800 5,940
UNI5407 2,100 6,930 2,100 6,930
UNI5408 2,400 7,920 2,400 7,920
Model
Minimum
resistance
Instantaneous power
rating
UNI1201 to UNI1205 20Ω 15kW
UNI2201 20Ω 15kW
UNI2202, UNI2203 15Ω 20kW
UNI3201 to UNI3205 5Ω 60kW
UNI1401 to UNI1405 40Ω 15kW
UNI2401 40Ω 15kW
UNI2402, UNI2403 30Ω 20kW
UNI3401 to UNI3405 10Ω 60kW
UNI4401 to UNI4405 5Ω 120kW
Model size
Unidrive &
Unidrive VTC
Unidrive LFT
Max fan speed Min fan speed
1 56 dB(A) 45 dB(A) 28 dB(A)
2 53 dB(A) 42 dB(A) 28 dB(A)
3 64 dB(A) 53 dB(A)
4 69 dB(A) 62 dB(A)
5 75 dB(A)
Model
size
AC terminals
DC
terminals
Ground terminal
1
Plug-in terminal block
0.5 N m / 4.4 lb in
M4 (Torx/slot-head screw)
3 N m / 2.2 lb ft
2
Plug-in terminal block
0.5 N m / 4.4 lb in
M4 (Torx/slot-head screw)
3 N m / 2.2 lb ft
3
M10 stud
15 N m / 11 lb ft
M10 stud
15 N m / 11 lb ft
4
M10 stud
15 N m / 11 lb ft
M10 stud
15 N m / 11 lb ft
5
M10 bolt & nut
25 N m / 22.1
lb ft
M10 hole
25 N m /
22.1 lb/ft
M10 stud
25 N m / 22.1 lb ft
Torque tolerance ±10%
Model Connection type Torque setting
All Plug-in terminal block 0.5 N m 4.4 lb in
Type Torque setting
M4 Pozidriv screw 0.5 N m 4.4 lb in
