Unidrive M300/HS30 Quick Start Guide 39
Issue Number: 7
* Only a value of 3 or 4 in this parameter is saved.
If Pr 30 is equal to 1 or 2, this value is not transferred to the EEPROM or the drive. If Pr 30 is set to a
3 or 4 the value is transferred.
For further information, please refer to Chapter 9 NV Media Card Operation on page 61.
Defines how the motor is controlled when the run signal is removed from the drive.
See the Control User Guide for further information.
Open-loop:
Set to 1 to enable Dynamic V to F mode in open-loop mode only.
0: Fixed linear voltage to frequency ratio (constant torque - standard load)
1: Voltage to frequency ratio dependant on load current. This gives a higher motor efficiency.
30 Parameter Cloning
RW Txt NC US*
OL
Ú
NonE (0), rEAd (1), Prog (2), Auto
(3), boot (4)
Ö
NonE (0)
RFC-A
Parameter string Parameter value Comment
NonE 0 Inactive
rEAd 1 Read parameter set from the NV Media Card
Prog 2 Programming a parameter set to the NV Media Card
Auto 3 Auto save
boot 4 Boot mode
31 Stop Mode
RW Txt US
OL
Ú
CoASt (0), rP (1), rP.dc I (2),
dc I (3), td.dc I (4), dis (5)
Ö
rP (1)
RFC-A
CoASt (0), rP (1), rP.dc I (2),
dc I (3), td.dc I (4), dis (5), No.rP (6)
Value Text Description
0 CoASt Coast stop
1 rP Ramp stop
2 rP.dc I Ramp stop + 1 second dc injection
3 dc I Injection braking stop with detection of zero speed
4 td.dc I Timed injection braking stop
5 dis Disable
6 No.rP No ramp (RFC-A mode only)
32 Dynamic V To F Select / Flux Optimization Select
RW Num US
OL
Ú
0 to 1
Ö
0
RFC-A
