Control Techniques Unidrive HS30 User Manual

8 Unidrive M300/HS30 Quick Start Guide
Issue Number: 7
1 Product information
1.1 Ratings
Model
Input
phases
Max.
cont
input
current
Max input
fuse rating
Nominal cable size
Output current
European USA
1 Ph 3 Ph Input Output Input Output
Max.
cont
output
current
Nominal
power
Motor
power
ph A A A
mm
2
mm
2
AWG AWG A kW hp
01100017 1 8.7 10 1 1 16 16 1.7 0.25 0.33
01100024 1 11.1 16
1 1 14 16 2.4 0.37 0.5
01200017 1 4.5 6
1 1 16 16 1.7 0.25 0.33
01200024 1 5.3 6
1 1 16 16 2.4 0.37 0.5
01200033 1 8.3 10
1 1 16 16 3.3 0.55 0.75
01200042 1 10.4 16
1 1 16 16 4.2 0.75 1
02100042 1 18.8 20
2.5 1 12 16 4.2 0.75 1
02100056 1 24 25
4 1 10 16 5.6 1.1 1.5
02200024 1 / 3 5.3/4.1 6 6 1 1 16 16 2.4 0.37 0.5
02200033 1 / 3 8.3/6.7 10 10 1 1 16 16 3.3 0.55 0.75
02200042 1 / 3 10.4/7.5 16 10 1 1 16 16 4.2 0.75 1
02200056 1 / 3 14.9/11.3 20 15 2.5/1.5 1 12/14 16 5.6 1.1 1.5
02200075 1 / 3 18.1/13.5 20 15 2.5 1 12 16 7.5 1.5 2
02400013 3 2.4 6 1 1 16 16 1.3 0.37 0.5
02400018 3 2.9
6 1 1 16 16 1.8 0.55 0.75
02400023 3 3.5
6 1 1 16 16 2.3 0.75 1
02400032 3 5.1
6 1 1 16 16 3.2 1.1 1.5
02400041 3 6.2
10 1 1 16 16 4.1 1.5 2
03200100 1 / 3 23.9/17.7 25 20 4 1.5 10/12 14 10 2.2 3
03400056 3 8.7
10 1 1 14 16 5.6 2.2 3
03400073 3 12.2
16 1.5 1 12 16 7.3 3 3
03400094 3 14.8
16 2.5 1.5 12 14 9.4 4 5
04200133 1 / 3 23.7/16.9 25 20 4/2.5 2.5 10 12 13.3 3 3
04200176 3 21.3
25 4 2.5 10 12 17.6 4 5
04400135 3 16.3
20 2.5 2.5 10 12 13.5 5.5 7.5
04400170 3 20.7
25 4 2.5 10 12 17 7.5 10
The nominal cable sizes shown in the table above, are provided as a guide only. Ensure
that the cables used conform to the local wiring regulations.
NOTE
