Unidrive M300/HS30 Quick Start Guide 51
Issue Number: 7
Displays the maximum heavy duty current rating of the drive.
Displays the software version in the drive.
Defines the mode of the drive.
This is the basic reference selected from the available sources.
The Pre-ramp Reference is the final output from the reference system that is fed into the ramp
system.
77 Maximum Heavy Duty Rating
RO Num ND NC PT
OL
Ú
0.00 to Drive HD Current Rating A
Ö
RFC-A
78 Software Version
RO Num ND NC PT
OL
Ú
0 to 99.99.99
Ö
RFC-A
79 User Drive Mode
RW Txt ND NC PT US
OL
Ú
OPEn.LP (1), RFC-A (2)
Ö
OPEn.LP (1)
RFC-A RFC-A (2)
81 Reference Selected
RO Num ND NC PT
OL
Ú
-Pr 02 to Pr 02 or Pr 01 to Pr 02 Hz
Ö
RFC-A
82 Pre-ramp Reference
RO Num ND NC PT
OL
Ú
-Pr 02 to Pr 02 or Pr 01 to Pr 02 Hz
Ö
RFC-A
