6 Basic parameters (Menu 0)
Menu 0 is used to bring together various commonly used parameters for basic easy set up of the
drive.
6.1 Menu 0: Basic parameters
RFC-A is not available on Unidrive HS30 drives.
Parameter
Range
(Ú) Default (Ö)
Type
OL RFC-A OL RFC-A
01 Minimum Speed 0.00 to Pr 02 Hz 0.00 Hz RW Num US
02 Maximum Speed 0.00 to 550.00 Hz
Def.50: 50.00 Hz
Def.60: 60.00 Hz
RW Num US
03 Acceleration Rate 1 0.0 to 32000.0 s/100 Hz 5.0 s/100 Hz RW Num US
04 Deceleration Rate 1 0.0 to 32000.0 s/100 Hz 10.0 s/100 Hz RW Num US
05 Drive Configuration
AV (0), AI (1), AV.Pr (2), AI.Pr (3),
PrESEt (4), PAd (5), PAd.rEF (6),
E.Pot (7), torquE (8), Pid (9)
AV (0) RW Txt PT US
06 Motor Rated Current 0.00 to Drive Rating A
Maximum Heavy Duty
Rating A
RW Num RA US
07 Motor Rated Speed* 0.0 to 33000.0 rpm
Def.50:
1500.0 rpm
Def.60:
1800.0 rpm
Def.50:
1450.0 rpm
Def.60:
1750.0 rpm
RW Num US
08 Motor Rated Voltage 0 to 240 V or 0 to 480 V
110V drive: 230 V
200V drive: 230 V
400V drive Def.50: 400 V
400V drive Def.60: 460 V
RW Num RA US
09
Motor Rated Power
Factor**
0.00 to 1.00 0.85 RW Num RA US
10 User Security Status
LEVEL.1 (0), LEVEL.2 (1), ALL (2),
StAtUS (3), no.Acc (4)
LEVEL.1 (0) RW Num ND PT
11
Start/Stop Logic
Select
0 to 6 0 RW Num US
15 Jog Reference 0.00 to 300.00 Hz 1.50 Hz RW Num US
16 Analog Input 1 Mode
4-20.S (-6), 20-4.S (-5),
4-20.L (-4), 20-4.L (-3),
4-20.H (-2), 20-4.H (-1), 0-20 (0),
20-0 (1), 4-20.tr (2), 20-4.tr (3),
4-20 (4), 20-4 (5), Volt (6)
Volt (6) RW Txt US
17
Bipolar Reference
Enable
Off (0) or On (1) Off (0) RW Bit US
18 Preset Reference 1 0.00 to Pr 02 Hz 0.00 Hz RW Num US
19 Preset Reference 2 0.00 to Pr 02 Hz 0.00 Hz RW Num US
20 Preset Reference 3 0.00 to Pr 02 Hz 0.00 Hz RW Num US
21 Preset Reference 4 0.00 to Pr 02 Hz 0.00 Hz RW Num US
22
Status Mode
Parameter 2
0.000 to 30.999 4.020 RW Num PT US
23
Status Mode
Parameter 1
0.000 to 30.999 2.001 RW Num PT US
24
Customer Defined
Scaling
0.000 to 10.000 1.000 RW Num US
25 User Security Code 0 to 9999 0 RW Num ND PT US
