6.2 Unidrive M300/HS30 parameter descriptions
Key:
Set Pr 01 at the required minimum output frequency of the drive for both directions of rotation. The
drive speed reference is scaled between Pr 01 and Pr 02. Pr 01 is a nominal value; slip
compensation may cause the actual frequency to be higher. When the drive is jogging, Pr 01 has no
effect.
Set Pr 02 at the required maximum output frequency for both directions of rotation. The drive speed
reference is scaled between Pr 01 and Pr 02. Pr 02 is a nominal value; slip compensation may cause
the actual frequency to be higher. The drive has additional over-speed protection.
Set Pr 03 at the required rate of acceleration. Note that larger values produce lower acceleration.
The rate applies in both directions of rotation.
Set Pr 04 at the required rate of deceleration. Note that larger values produce lower deceleration.
The rate applies in both directions of rotation.
RW
Read /
Write
RO
Read
only
Num
Number
parameter
Bit
Bit
parameter
Txt Text string Bin
Binary
parameter
FI Filtered
ND
No
default
value
NC
Not
copied
PT
Protected
parameter
RA
Rating
dependent
US User save PS
Power-down
save
DE Destination
01 Minimum Speed
RW Num US
OL
Ú
0.00 to Pr 02 Hz
Ö
0.00 Hz
RFC-A
02 Maximum Speed
RW Num US
OL
Ú
0.00 to 550.00 Hz
Ö
Def.50: 50.00 Hz
Def.60: 60.00 Hz
RFC-A
03 Acceleration Rate 1
RW Num US
OL
Ú
0.0 to 32000.0 s/100 Hz
Ö
5.0 s/100 Hz
RFC-A
04 Deceleration Rate 1
RW Num US
OL
Ú
0.0 to 32000.0 s/100 Hz
Ö
10.0 s/100 Hz
RFC-A
