Main Ratings
* Above 40°C (104°F), the current rating is
reduced by 1.6A/
°C (0.88A/°F)
AC Supply Ratings
Voltage (phase-to-phase and phase-to-ground):
480V +10%
AC supply frequency: 48 to 62 Hz
Ground Leakage Current
The ground-leakage current, phase-to-phase and
phase-to-ground, when the AC supply is 400V at
50Hz is as follows:
For other AC supply voltages and currents, scale
the value of leakage current proportionally.
Discharge Resistors
A and B: 330 KΩ internally between phases, with
the star point connected by a 1M resistor to ground.
C to G: 10 MΩ internally between each phase
and ground.
Maximum Current Overload
150% of rated current for 60 seconds.
Overall Dimensions
Balanced 5.6mA 7.4mA 55mA
One phase disconnected 41mA 57.9mA 350mA
CONDITION A B C to G
A25
B 2.7 6
C 7.4 16
D818
E 12.3 27
F1635
G3577
FILTER TYPE kg lb
Filter type Dimension
HWD
A 396mm 50mm 113mm
15
9
/16 in 1
15
/16 in 4
7
/16 in
B 396mm 75mm 113mm
15
9
/16 in 2
15
/16 in 4
7
/16 in
C 330mm 190 mm 145mm
13 in 7
1
/2 in 5
11
/16 in
D 330mm 190mm 145mm
13 in 7
1
/2 in 5
11
/16 in
E 440mm 200mm 145mm
17
5
/16 in 7
7
/8 in 5
11
/16 in
F 490mm 200mm 145mm
19
1
/4 in 7
7
/8 in 5
11
/16 in
G 380mm 495mm 250mm
14
5
/16 in 19
1
/2 in 9
13
/16 in
Weights
RFI Filter Ratings
A 4200-0010 10A 25W IP20 50°C (122°F) <30°C (86°F)
B 4200-0027 27A 40W IP20 50°C (122°F) <40°C (104°F)
C 4200-1051 50A 60W IP00 50°C (122°F) <40°C (104°F)
D 4200-1071 75A 100W IP00 50°C (122°F) <40°C (104°F)
E 4200-1111 110A 120W IP00 50°C (122°F) <40°C (104°F)
F 4200-1171 170A 150W IP00 40°C (104°F) <55°C (131°F)
G 4200-1302 300A 300W IP00 50°C (122°F) <40°C (104°F)
Type Part number
Max.
continuous
current
Power
dissipation at
rated current
Ingress
protection
Max. ambient
temperature at
rated current
Case
temperature rise
at rated current
To Next Page
