Control Techniques Unidrive Servo Series User Manual

drive overview
Connectivity
UD73 - Profibus DP
UD74 - Interbus S
UD77 - DeviceNet
UD75 - CT Net
UD76 - Modbust +
UD71 - RS232/485
HMI - Operator Interfaces
Feedback
Standard - Encoder
UD53 - Resolver
UD52 - Sin/cos encoder
Unimotor
Brushless AC Servo motors to 70Nm
On request:
- Brushless >70NM-1850Nm
- Asynchronous >70NM-2500Nm
Motor accessories: - cables, fan
cowlings, brakes, planetary geared
motors
Unidrive Servo
& Unimotor
The complete multi purpose
Servo package with
high flexibility
& functionality
Model size 3
Model size 2
Model size 1
Model size 4
Motion Intelligence
UD70 - Applications module
UD78 - High performance servo
UD50 - Extended I/O
UD51 - 2nd Encoder
Unisoft - Programming software
SYPT - Systems programming tool
CTSS - Servo sizing software tool
Power Range 380-480V
Size 1 - 0.75 to 4kW
Size 2 - 5.5 to 11kW
Size 3 - 15 to 37kW
Size 4 - 45 to 110kW
Size 5 - >110kW
Line regeneration capability
4
75
95
115
142
190
