Specification
Physical
Insulation Class Class H, BS EN 60034-1.
Dimensional Accuracy IEC 72-1, Class N (normal
class), Class R (precision
class) is optional.
Degree of Balance Rotor balanced to ISO 1940
(BS 6861) G 6.3 (half key
convention to ISO 8821).
Temperature Monitoring PTC thermistor, 170˚C
switch temperature.
Bearing System Preloaded ball bearings.
Electrical Connections Connector or terminal box
for power and brake;
connector for feedback
devices and thermistor.
Flange Mounting IEC 72-1 as standard/
NEMA MG-7 optional.
Output Shaft Plain shaft as standard.
Output key is optional
(to IEC 72-1).
Environmental
Ingress Protection Motor fitted with mating
connector and cable:
IP65.
Speed up to 3000RPM:
IP65.
Speed above 3000RPM:
IP54.
Operating Temperature Specified performance at
40˚C ambient.
Storage Temperature -20˚C to 70˚C.
Insulation Class H (180˚C)
Temperature Rise 125˚C over ambient of
40˚C Max.
100˚C over ambient of
40˚C Typical.
Relative Humidity 90% Non condensing
Use the information given in the illustration below to
create an order code for a Unimotor. The details in the blue
band are an example of an order reference.
Ordering Information
Frame
Size:
75
95
115
142
190
Rated Speed (Standard):
30 - 3000 rpm
20 - 2000 rpm
40 - 4000 rpm ***
Stator Length:
A, B, C, D, E
Brake:
0 - Non fitted
1 - Brake fitted 24V dc
Connection Type:
C - Connection
H - Hybrid
T - Terminal*
Output Shaft Key:
B - Standard without Key
A - With Key
Inertia:
A - Standard
B - High
Feedback Device:
C - Incremental Encoder
D - CT Coder + SL Electronics**
G - Sin/Cos Encoder SCM60 (multi-turn)
H - Sin/Cos Encoder SCS60 (single turn)
A - Resolver 55RSS116
Flange Mounting
A - IEC, B - NEMA
Motor Type:
UM - Unimotor
SL - Speed Loop
Control
* Available with resolver
feedback only.
** Available for SL Motors
only.
*** Other speeds are available
on special request
UM
ORDER REFERENCE EXAMPLE
B300 CB C A
motor technical specification
