36
Cable Description (2.5mm
2
) PUR (2.5mm
2
) PUR
Shielded Power, Shielded Power,
without Brake with Brake
Cable Type PSBA-- PBBA--
Power Conductors 4 x 2.5mm
2
4 x 2.5mm
2
Brake Supply Wires
-
1 x (2x1) mm
2
Conductor Type Copper stranded to DIN VDE 0295
Class 6, IEC 228 Class 6, CEI 20-29
Class 6; 147 x 0.15mm;13 AWG
Insulation Material PET - complies: VDE 0250 part 1 tab 4
Core Identification Black, printed white: U, VV, WWW, GY
Brake Signal Pair
Brake Conductors - Copper stranded 19 x 0.25mm
Brake Insulation - PET - complies: VDE 0250 part 1 tab 4
Brake Pair Shield - Tinned copper spiralled covering ³90%
Brake Core Identification - Black and white
Taping - Soft tape
Shield Tinned copper braid Tinned copper braid
covering ³85% covering ³85%
Shield Diameter 10.5mm 10.5mm
Outer Jacket Polyurethane complies: Polyurethane complies:
VDE 025-818 black VDE 025-818 black
Outer Jacket Diameter 12.8 mm± 4% 12.8 mm ± 4%
Voltage (power) 600 V / 1000 V 600 V / 1000 V
Voltage (brake pair) - 250 V
Dielectric Strength 3000 V 3000 V
(power)
Dielectric Strength - 1000V
(brake pair)
Insulation Resistance >10 MOhm/km >10 MOhm/km
(power)
Capacitance 110 pf/m 110 pf/m
(phase - phase)
Capacitance 190 pf/m 190 pf/m
(phase - screen)
Bending Radius (min) 10 x diameter, dynamic
laying (150 mm)
Speed (max) 180 m/min 180 m/min
Acceleration (max) 7 m/s
2
7 m/s
2
Bending Life (min) 5 million cycles 5 million cycles
Operating Temperature -10˚C to + 80˚C -10˚C to + 80˚C
Storage Temperature -30˚C to + 80˚C -30˚C to + 80˚C
Pulling Strength 20 N/mm
2
20 N/mm
2
(max, dynamic)
Pulling Strength 50 N/mm
2
50 N/mm
2
(max, fixed)
Weight 160 kg/km 160 kg/km
Specification - Shielded Power Cable Options 2.5mm
2
accessories
PUR Power Cables
