Engine Safety Configuration
Sender Check Bypass Time Period Selection
Fuel Level Check On/Off Selection
Low Fuel Level Pre Alarm % Selection
Low Fuel Level Alarm % Selection
Fuel Level Alarm Delay Time Selection
Oil Pressure Check On/Off Selection
Low Oil Pressure Pre Alarm % Selection
Low Oil Pressure Alarm % Selection
Oil Pressure Alarm Time Delay Selection
Engine Temperature Check On/Off
Engine Temperature Pre Alarm Selection
Engine Temperature Alarm Selection
Engine Temperature Alarm Time Delay Selection
Battery Volt Check On/Off
Low Battery Volt Pre Alarm Selection
High Battery Volt Pre Alarm Selection
Battery Volt Trim Setting
Over Speed Alarm On/Off
Over Speed Alarm RPM Setting
Over Speed Alarm Time Delay Selection
(5)
Module Configuration
Display Contrast - N/A
Display Backlight - N/A
Display Intensity - N/A
English/Metric Selection
Hourmeter Source
Hourmeter Setting (if not ECU)
Battery Volt Source
Clear Operation Log Yes/No
Clear Alarm Log Yes/No
(6)
CAN Configuration
Source Address (Default = 0)
Faults Transmit (All) All=constant ok or fault message
CAN bus output for engine speed, oil pressure, engine temperature and fault codes are provided on pins 7 and 8 on
the module’s 14 pin connector.
