Configuration Menus
(1)
Input Configuration
Digital Input 1 Setup (NO/NC, Action, Message, When Active, Delay)
Digital Input 2 Setup (NO/NC, Action, Message, When Active, Delay)
Digital Input 3 Setup (NO/NC, Action, Message, When Active, Delay)
Digital Input 4 Setup (NO/NC, Action, Message, When Active, Delay)
Digital Input 5 Setup (NO/NC, Action, Message, When Active, Delay)
Digital Input 6 Setup (NO/NC, Action, Message, When Active, Delay)
Digital Input 7 Setup (NO/NC, Action, Message, When Active, Delay)
Digital Input 8 Setup (NO/NC, Action, Message, When Active, Delay)
Digital Input 9 Setup (NO/NC, Action, Message, When Active, Delay)
(2)
Output Configuration
Relay Output 1 – Pre Set to Pre Alarm
Relay Output 2 - Pre Set to Fuel/Run
Relay Output 3 - Pre Set to Alarm
Relay Output 4 - Pre Set to Crank Signal
Relay Output 5 Setup (Function, Polarity, Initial State)
Relay Output 6 Setup (Function, Polarity, Initial State)
Relay Output 6 Setup (Function, Polarity, Initial State)
Relay Output 7 Setup (Function, Polarity, Initial State)
Relay Output 8 Setup (Function, Polarity, Initial State)
(3)
Throttle Configuration
Throttle Type - Throttle Type Selection (Default = Vernier)
TSC Mode – (Default = Primary)
TSC Minimum Speed (Default = 800 rpm)
TSC Maximum Speed (Default = 2300 rpm)
TSC Bump Speed (Default = 20 rpm)
TSC Ramp Rate ( Default = 100 rpm/second)
Throttle Curve (Default = Linear)
Multi-State Speed 1 (Default = 800 rpm)
Multi-State Speed 2 (Default = 800 rpm)
Multi-State Speed 3 (Default = 800 rpm)
Multi-State Speed 4 (Default = 800 rpm)
