Controls C4F-F10198 User Manual

CONTROLS, INCORPORATED
C O N T R O L S Y S T E M S & S O L U T I O N S
- 18 -
(4)
Engine Safety Configuration
Sender Check Bypass Time Period Selection
Fuel Level Check On/Off Selection
Low Fuel Level Pre Alarm % Selection
Low Fuel Level Alarm % Selection
Fuel Level Alarm Delay Time Selection
Oil Pressure Check On/Off Selection
Low Oil Pressure Pre Alarm % Selection
Low Oil Pressure Alarm % Selection
Oil Pressure Alarm Time Delay Selection
Engine Temperature Check On/Off
Engine Temperature Pre Alarm Selection
Engine Temperature Alarm Selection
Engine Temperature Alarm Time Delay Selection
Battery Volt Check On/Off
Low Battery Volt Pre Alarm Selection
High Battery Volt Pre Alarm Selection
Battery Volt Trim Setting
Over Speed Alarm On/Off
Over Speed Alarm RPM Setting
Over Speed Alarm Time Delay Selection
(5)
Module Configuration
English/Metric Selection
Hour Meter Source
Hour Meter Setting (if not ECU)
Battery Volt Source
Pre Alarms Displayed
Clear Operation Log Yes/No
Clear Alarm Log Yes/No
(6)
CAN Configuration
Source Address (Default = 44)
TSC1 Address (Default = 44)
Engine Address (Default = 0)
Engine Type (Default = John Deere)
Oil / Fuel Transmit
Fault Transmit

Controls C4F-F10198 Specifications

General

Brand	Controls
Model	C4F-F10198
Category	Control Panel
Language	English
