ENGINE PARAMETER CONFIGURATION
The Parameter Configuration menu allows you to configure each critical engine parameter to the
source of the information. Sender type, scale and input channel to the module can be selected here.
You will first select the parameter, then the properties associated with each one.
Heading
Default
Range
Engine Type
Electronic FT4
Electronic FT4/iT4/T3/T2
Parameter
Fuel Level
Voltage
Hour meter
ASP1
ASP2
Fuel Level Sender
S-W
SW/VDO/0-90ohm
Fuel Channel
Plug A Pin 5
No Options
Voltage Source
Elect-J1939
Batt-J1939/Alt-J1939/Elect-J1939/Internal
Batt Volt Trim (100mV) (Internal Only)
0
Hour meter
Engine ECU
Internal/Engine ECU
Hour meter (Internal Only)
0 Hours
APS1 OOR Pre Alarm
Always
Always/Run/Off
APS1 Min.
0.5 V
0.5 – 4.5 V
APS1 Max.
4.5 V
0.5 – 4.5 V
APS1 Actual
APS1 Learned Minimum
100 V100
APS1 OP Range Tolerance
20%
APS1 Learned Reset
No
APS2 Validation
On
APS2 Validation Tolerance
20%
APS2 OOR Pre Alarm Check
Always
APS2 Minimum
0.5 V
APS2 Maximum
4.5 V
APS 2 Actual
APS2 OP Range Tolerance
20 %
