OPERATOR MENU
Emissions Parameters
This menu allows for the viewing of the engine emissions data as broadcast by the ECU by pressing
the up arrow button. This data includes:
 DOC Inlet Temperature
 DPF Soot Load
 DPF Inlet Temperature
 Time at Last Regeneration
 DPF Outlet Temperature
 Active Regen Status
 Regen Options
 Regen Inhibit Status
 DPF Differential Pressure
Active Fault Codes
This menu allows for the viewing of any Active Fault Codes as broadcast by the engine ECU by
pressing the up arrow button.
Stored Fault Codes
This menu allows for the viewing of any Stored Fault Codes as broadcast by the engine ECU by
pressing the up arrow button.
Operation Event Log
The operation log will record the engine start and stop events and tag them with the engine run
time hours. The Alarm can be viewed in the Operator menu area and can be cleared in the Module
Configuration section of the Controller Setup menu.
Alarm Event Log
Any monitored pre alarm or alarm will be recorded in the Operator menu section. The event will be
tagged with the actual engine run time hours at which the event occurred. The log stores the last 32
events and can be cleared in the Module Configuration section on the Controller Setup menu.
Engine Parameters
This menu allows for the viewing of unique engine information broadcast by the ECU by pressing
the up arrow buttons. This information includes:
 Total Hours
 Engine Torque
 Requested TSC
 Coolant Temperature
 Rated Speed
 Fuel Rate
 Low Idle Speed
 Manifold Temperature
 Load at RPM
 Potential Voltage
