INPUT CONFIGURATION
The Input Configuration menu allows you to set up a discreet switch input that can be treated as Pre
Alarm or Alarm. Common text messages for power unit applications are preloaded. A custom
message can be assigned to the input.
Heading
Default
Range
Configure
Channels
Channels/Custom Message
Digital Input
1
Normally
Open
Open/Closed
Action
Pre Alarm
Pre Alarm/Alarm/Throttle Up/Throttle Down/Neutral
Switch/Parking Brake/Hydro Throttle/Active Faults/Stored Faults
Message
Water in Fuel
See List
Check
Off
Off/Always/Run
Default Settings
1
Water in Fuel
Configure
Custom Message
Top Line Message
Alpha Numeric 14 Characters Max
Bottom Line
Message
Alpha Numeric 14 Characters Max
Available Input Messages
Low Water
Low Oil
Low Engine Oil
High Temperature
Low Pressure
Low Pressure-Low Speed
Low Pressure-Hi Speed
External Shutdown
E-Stop
Remote E-Stop
High Pump Temp
Low Pump Oil
Low Fuel Level
Override Active
Polish Filter
Low Hydraulic Fluid
Vacuum High
Hi Hydraulic Temp
Low Hydraulic Oil
Inlet Pressure Loss
Pipe Pressure Alarm
Low Coolant Level
Air Filter
Air Filter Restriction
Oil Tank Temp
Oil Tank Level
Remote Disabled
Shutdown Override
Access Door Closed
Pivot Shutdown
Pump Pressure
Water in Fuel
None
