The control panel also has the ability to monitor the engine vitals if configured. The ability to set pre
alarms and alarms in the panel is supported to back up the ECUs safeties in the event the ECU
shutdowns were not enabled for some reason or a more conservative setting is desired. If the
parameter falls outside of the normal operating range, the control panel will stop the engine by
removing power to the fuel solenoid or ignition circuit. The display will indicate the reason for the
shutdown and a red alarm lamp will be illuminated in the upper left corner of the module.
Indicator Lamps
.
Exhaust High
Temperature
Lamp
