11VA/AVA/AF IO&M B51146-004
AFD-C
Airflow
4
5
3
2
1
Part No. Description
1 Drum Weldment
2 Propeller
3 Prop Bushing
4 Motor
5 Motor Mounting Box
AFDV-C
Airflow
4
5
3
2
1
6
Part No. Description
1 Drum Weldment
2 Propeller
3 Prop Bushing
4 Motor
5 Motor Mounting Box
6 Vane Section
