WLAPGMN User Manual
5
2.1 Environment Requirements
• A computer has configured TCP/IP
• An availabe RJ-45 port on an Ethernet Hub/Switch/Router/Modem
• A WLAN adapter which compliance with IEEE802.11g, IEEE802.11b, or
IEEE802.11 standard.
• Microsoft Internet Explorer 4.0 or Netscape Navigator 4.78 above
browser.
2.2 Install the product
(1) Prepare a hub/router which has connected with ADSL cable and PC.
(2) Insert the cable connector into the LAN port of WLAPGMN.
(3) Insert the other connctor of the cable into the Hub or Router’s LAN
port.
(4) Insert the power connector into WLAPGMN.
(5) Insert the power adapter into socket, meanwhile you will see the
Power and LAN LED blink.
