8
TD 204
COMPRESSOR (CONT’D)
Hertz 60 60 60 60 60 60
LRA 96 96 96 95.6 95.6 95.6
RLA 13.5 13.5 13.5 23.9 23.9 23.9
CONDENSER FAN MOTOR (Air-Cooled System only) or
AIR CIRCULATION FAN MOTOR (Water-Cooled and Remote Systems only)
Volts 230 230 230 230 230 230
Phase 1 1 1 1 1 1
Hertz 60 60 60 60 60 60
Amps Running 0.89 X 2 0.36 0.36 0.4 0.36 0.36
Watts 50 W X 2 6 W 6 W 1/15 HP 6 W 6 W
WATER PUMP
Volts 230 230 230 230 230 230
Phase 1 1 1 1 1 1
Hertz 60 60 60 60 60 60
Amps Running 0.5 0.5 0.5 0.5 0.5 0.5
HP 1/30 1/30 1/30 1/30 1/30 1/30
