2-13
G21, G23, G25, 210 and 230
G21
Description
1. Bow Lifting Ring
2. Bow Navigation/Docking Light
3. 12V Port
4. Belly Ballast Tank Vent
5. Battery Selector Switch/Power Management Access (PMA)/12V Port
6. Dash Pod and Console
7. Battery Maintenance Plug
8. T-Handle Drain Plug
9. Engine Cooling Water Intake Shutoff Valve
10. Engine Cooling Water Intake Strainer
11. Starboard Ballast Tank Vent
12. Forward Bilge Pump Outlet
13. Fuel Tank Fill
14. Fuel Tank Vent
15. Trunk Storage Access
16. CE Bilge Pump Filters (International Only)
17. CE Fire Suppressor
18. Stern Lifting Ring
19. Transom Watersports Tow Point
20. Boarding Platform
21. Rudder Port Remote Lube Fitting
22. Rear Bilge Pump Outlet
23. Port Ballast Tank Vent
24. Removable Cooler
25. Flight Control Tower Watersports Tow Point
26. Seacock Access (shut-off valves, ballast intake/drain)
27. Batteries*
28. Observer’s Seat/Storage Access
29. Glove Box/Stereo/Auxiliary Input/12V Port
30. Waste Basket
31. Observer’s Seat Heater On/Off Button (optional)
* The primary battery is on the port side and the optional secondary battery is on
the starboard side. The battery selector switch is located in the PMA box under
the helm.
