Belly Ballast Tank and Bilge System - 210, 230
CORC0229
BILGE DRAIN
HULL VENT
AFT
BILGE PUMP
BELLY TANK
INTAKE/DRAIN
VALVE
BELLY TANK
PUMP
BELLY BALLAST
TANK
FORWARD
BILGE PUMP
