2-1
Section 2
G21, G23, G25, 210 and 230
Specifications
G21
Length Overall.........................................................21' 6" (6.55 m)
Length with Platform..............................................23' 9" (7.24 m)
Lifting Ring Spacing ..........................................20' 1.75" (6.14 m)
Beam...........................................................................102" (2.59 m)
Draft..............................................................................25" (0.64 m)
Approximate Dry Weight* .............................5,200 lbs (2,359 kg)
Fuel Capacity...............................................46.5 Gallons (176.1 L)
Maximum Capacity .........................14 People (2,200 lbs/998 kg)
Horsepower Range .............................343 to 550 (256 to 410 kw)
Gear Reduction Ratio...............................................1.48:1 to 2.0:1
Maximum Factory Ballast Capacity................2,850 lbs (1,293 kg)
* Weights are estimates and can vary from options and equipment
added.
G23
Length Overall .............................................................23' (7.01 m)
Length with Platform..............................................25' 3" (7.70 m)
Lifting Ring Spacing ..........................................21' 6.25" (6.56 m)
Beam...........................................................................102" (2.59 m)
Draft..............................................................................25" (0.64 m)
Approximate Dry Weight* .............................5,400 lbs (2,449 kg)
Fuel Capacity..................................................65 Gallons (246.1 L)
Maximum Capacity ......................16 People (2,500 lbs/1,134 kg)
Horsepower Range .............................409 to 550 (305 to 410 kw)
Gear Reduction Ratio...............................................1.48:1 to 2.0:1
Maximum Factory Ballast Capacity................2,850 lbs (1,293 kg)
* Weights are estimates and can vary from options and equipment
added.
