G21, G23, G25, 210 and 230
2-15
G23 and G25
Description
1. Bow Lifting Ring
2. Bow Navigation/Docking Light
3. 12V Port
4. Belly Ballast Tank Vent
5. Battery Selector Switch/Power Management Access (PMA)/12V Port
6. Driver’s Glove Box/12V/Tower Cam DVR (Opt)/USM-LINC/Aux
Input
7. Dash Pod and Console
8. Battery Maintenance Plug
9. T-Handle Drain Plug
10. Engine Cooling Water Intake Shutoff Valve
11. Engine Cooling Water Intake Strainer
12. Starboard Ballast Tank Vent
13. Forward Bilge Pump Outlet
14. Fuel Tank Fill
15. Fuel Tank Vent
16. Trunk Storage Access
17. CE Bilge Pump Filters (International Only)
18. Stern Lifting Ring
19. Boarding Platform
20. CE Fire Suppressor
21. Transom Watersports Tow Point
22. Aft Cooler
23. Rudder Port Remote Lube Fitting
24. Rear Bilge Pump Outlet
25. Port Ballast Tank Vent
26. Flight Control Tower Watersports Tow Point
27. T-Handle Drain/Seacock Access (shut-off valves, ballast
intake/drain)
28. Batteries*
29. Removable Cooler
30. Observer’s Seat/Storage Access
31. Glove Box/Stereo/Auxiliary Input/12V Port
32. Waste Basket
33. Observer’s Seat Heater On/Off Button (optional)
* The primary battery is on the port side and the optional secondary battery is on
the starboard side. The battery selector switch is located in the PMA box under
the helm.
