CorroVenta VENTOVIND PRO - Technical Data; Control Panel; Control Unit Ventovind Pro; Sensor Unit Ventovind PRO

User manual VentoVind™ PRO
© Corroventa Avfuktning AB
2021.05
17 (18)
Technical data
Control panel
Height x Width x Depth, mm
85 x 150 x 30
Weight, g
20
Voltage AC adapter
+5 VDC / 800 mA
Control unit VentoVind™ Pro
Cable length, m
5
Weight, g
50
Fuse Type
MAX T16A 250VAC
Voltage, VAC
230
Frequency, Hz
50
Sensor unit VentoVind
™
PRO
Height x Width x Depth, mm
110 x 100 x 50
Cable length, m
15
Weight, g
150
VentoVind
™
PRO Villa fan, KVK Silent 160
Voltage, V
230
Frequency, Hz
50
Phase
1
Power, W
88
Current, A
0.402
Maximum air flow m
3
/s
0.153
Speed, p.m..
2647
Max. temperature of transported air, °C
70
Max. temperature of transported air during voltage
control, °C
70
Sound pressure level, 3m, db.(A)
37
Weight, kg
17.2
Insulation class, motor
F
Enclosure class, motor
IP44
Capacitor, off
2.5
Duct connection: circular, intake / Exhaust. mm
160
