20 21
24” Burner and Orifice Characteristic Table
Refer to the following chart for correct gas orifice spud placement�
IMPORTANT: Save the orifices removed from the appliance for future use�
Burner Position
Orifice Gas Pressure Rate
Diam� (mm) Type [i�w�c] [BTU/h]
Auxiliary Front R
1�10 NG 4” 5000
0�70 LP (Propane) 10” 5000
Semi-Rapid Rear L
1�29 NG 4” 6900
0�80 LP (Propane) 10” 6500
Triple Front L
0�99 x 5 NG 4” 17400
0�56 x 5 LP (Propane) 10” 15000
Semi-Rapid Raer R
1�29 NG 4” 6900
0�80 LP (Propane) 10” 6500
Broil burner Top
1�4 NG 4” 7900
0�85 LP (Propane) 10” 7900
Bake burner Bottom
1�7 NG 4” 10700
1�0 LP (Propane) 10” 10800
24” SERIES OF PRODUCTS
Gas Type: Natural Gas 4” Test Point Pressure
Burner Injector Size (mm) Burner Rating (BTU)
Large 0�99 mm x 5 17400
Small 1�29 mm 6900
Tiny 1�10 mm 5000
Top Burner 1�40 mm 7900
Bottom Burner 1�70 mm 10700
Gas Type: LPG 10” Test Point Pressure
Burner Injector Size (mm) Burner Rating (BTU)
Large 0�56 mm x 5 15000
Small 0�80 mm 6500
Tiny 0�70 mm 5000
Top Burner 0�85 mm 7900
Bottom Burner 1�10 mm 10800
WARRANTY AND SERVICE
For full warranty details on this product please visit:
http://www.cosmoappliances.com/warranty
TO RECEIVE WARRANTY SERVICE, YOUR
PRODUCT MUST BE REGISTERED. TO REGISTER, VISIT:
WWW.COSMOAPPLIANCES.COM/WARRANTY
IMPORTANT
Do Not Return This Product To The S tore If
you have a problem with this product, please contact
Cosmo Customer Support at
1-888-784-3108.
DATED PROOF OF PURCHASE, MODEL #, AND SERIAL #
REQUIRED FOR WARRANTY SERVICE
IMPORTANT
Ne pas Réexpédier ce Produit au Magasin
Pour tout problème concernant ce produit, veuillez contacter
le service des consommateurs Cosmo Customer Support au
1-888-784-3108.
UNE PREUVE D’ACHAT DATEE EST REQUISE POUR BENEFICIER DE LA GARANTIE.
IMPORTANTE
No regrese este producto a la tienda
Si tiene algún problema con este producto, por favor contacte el
AYUDA AL CLIENTE COSMO al
1-888-784-3108
(Válido solo en E.U.A).
NECESITA UNA PRUEBA DE DE COMPRA FECHADA, NÚMERO DE
MODELO Y DE SERIE PARA EL SERVICIO DE LA GARANTÍA
